8.42mp 4K HDMI Camera HD5602 for Measure
Model:8.42mp 4K HDMI Camera HD5602 for Measure
Category:4K HDMI Camera
Brand:Oi-Instruments
Contact name:Orlenda Tan
Telephone:18962123364
Email:orlenda@oi-instruments.com

◆ 8.42 megapixel Sony new generation high dynamic range CMOS image sensor is adopted;
◆ 1 / 1.8 Inch image sensor is adopted;
◆ HDMI up to 4K 60 frame image output;
◆ support photographing, JPG format;
◆ support manual one touch exposure
◆ support manual one key white balance, and red, green and blue can be adjusted;
◆ provide 8 line drawing functions, and the line color and position can be adjusted;
◆ support USB flash disk storage;
◆ support mouse operation;
◆ take photos without shaking, and the image is clearer;
◆ support Chinese / English / complex languages (default English);
◆ support the saving of shutdown setting parameters;
◆ adopt CNC finish milling technology to process aluminum alloy shell;
Model: | HD5602 |
Resolution: | 8.42MP |
Sensor: | 1/1.8" |
Pixel Size: | 2um*2um |
Measurement: | Built-in Measurement Function |
HDMI: | 3840*2160 @ 60FPS 1920*1080 @ 60FPS |
USB: | USB2.0*2 (mouser,USB flash disk) |
Lens: | C/CS |
Exposure: | Auto/ A key exposure |
White Balance: | Auto/ A key WB, RGB adjustable |
Storage: | Support U disk storage, mouse operation |
Input Voltage: | DC 5V-12V |
Lineation: | Support 8 groups of lines, color, thickness and position adjustable |
Center Line: | Support |
Startup Screen: | The startup screen can be customized |
Language: | English/Chinese |
Mirror: | Supprt horizontal and vertical mirroring |
Camera Size: | 60*60*58mm |
Package Size: | 145*130*70mm |
